ZS-2L 2-layer manure air dryer
•Function：The equipment integrates a hot air recovery system and a fecal air drying system to achieve effective utilization of hot air and rapid drying of feces.
•Advantage：Using waste heat from poultry and livestock houses as a heat source to reduce operating costs; Reduce energy consumption, in line with the concept of sustainable development; Reduce the volume of feces for easy subsequent treatment and utilization.
Refer to：50000 to 150000 chicken coops Processing fecal volume：About3600tons/year
The Zhongsai poultry manure air dryer is an efficient poultry manure drying equipment developed for the treatment of chicken manure in large chicken farms.
This device mainly uses the hot air discharged from the tail end of the chicken coop or
outdoor air to dry wet chicken manure through a high-pressure fan, and reduces the moisture content in the chicken manure to about 20%.
Technical parameters of drying equipment
1.）Drying parameters of poultry manure
Drying category： Poultry
Max number： 100000 chickens
Feed moisture content： 75%
Discharge moisture content： 20%
2.）Production parameters：
Processing fecal volume： About3300tons/year
Quantity of finished dry manure： About1100tons/year
3.）Application Parameters：
Types that can beprocessed： Chicken manure and other poultry manure
This design is based on past design experience of the same equipment.
4.）Electric Data
a)Dry air data：
Maximum input air pressure： 120Pa
Enter air category： Chicken coop air and natural wind
Rainy season heat source supply： hot blast stov（Optional）
Maximum air volume： ≤260000 m³/h
b)Power parameter：
Single-phase voltage： 220[V]
Phase voltage： 3×380[V+N+PE]
Frequency： 50[Hz]
Voltage tolerance range： ±10[％]
Protection type： IP54
Power supply capacity: 45KVA
5.）Operation condition：
Ambient temperature：0~+40°C]
Only for approved manure materials
Drawiny：The formal design drawings of the poultry manure drying equipment shall be provided to the buyer for confirmation within 15 days after receiving the deposit and confirming the appropriate installation size of the relevant site
Pay attention to：
In extreme weather conditions such as rainy season or low temperature and high humidity, if there is no hot air stove, the drying effect of the equipment will be affected to a certain extent.
